45degree grease fitting
| thread | length | hex | type |
| 1/4-28" | 19mm | 7mm | UNF |
| 5/16-24" | 21mm | 10mm | UNF |
| 3/8-24" | 21mm | 11mm | UNF |
| 7/16-20" | 25mm | 12mm | UNF |
| 1/2-20" | 30mm | 14mm | UNF |
| 9/16-18" | 34mm | 15mm | UNF |
| 5/8-18" | 25mm | 17mm | UNF |
| 5/16-18" | 21mm | 8mm | UNC |
| 3/8-16" | 21mm | 10mm | UNC |
| 1/8-27" | 23mm | 11mm | SAE |
| 1/4-18" | 25mm | 14mm | SAE |
90degree grease fitting
| thread | length | hex | type |
| 1/4-28" | 19mm | 7mm | UNF |
| 5/16-24" | 21mm | 10mm | UNF |
| 3/8-24" | 21mm | 11mm | UNF |
| 7/16-20" | 25mm | 12mm | UNF |
| 1/2-20" | 30mm | 14mm | UNF |
| 9/16-18" | 34mm | 15mm | UNF |
| 5/8-18" | 25mm | 17mm | UNF |
| 5/16-18" | 21mm | 8mm | UNC |
| 3/8-16" | 21mm | 10mm | UNC |
| 1/8-27" | 23mm | 11mm | SAE |
| 1/4-18" | 25mm | 14mm | SAE |
| thread | length | hex | type |
| 1/4-28" | 13mm | 7mm | UNF |
| 5/16-24" | 16mm | 10mm | UNF |
| 3/8-24" | 17mm | 11mm | UNF |
| 7/16-20" | 18mm | 12mm | UNF |
| 1/2-20" | 21mm | 14mm | UNF |
| 9/16-18" | 23mm | 15mm | UNF |
| 5/8-18" | 25mm | 17mm | UNF |
| 5/16-18" | 16mm | 8mm | UNC |
| 3/8-16" | 18mm | 10mm | UNC |
| 1/8-27" | 18mm | 11mm | SAE |
| 1/4-18" | 23mm | 14mm | SAE |
